How to create a custom GitHub Action using TypeScript

In this article, we’ll create a custom reusable GitHub Action using TypeScript. As covered in our article on reusing GitHub workflows and steps, GitHub Actions allow you to automate your software development workflows. By creating a custom GitHub Action, you can extend the functionality of GitHub Actions to suit your specific needs.

We will create a simple GitHub Action to replace GitHub’s broken Pull Request review process. This custom GitHub Action will automatically approve Pull Requests that meet specific criteria.

Start with GitHub’s Action template

GitHub provides a template for creating a new GitHub Action using TypeScript. You can use this template to get started quickly. The template includes the necessary files and structure to create a new GitHub Action. Anything unnecessary can be removed or modified to suit your requirements.

Follow the instructions in the template’s README to set up your action.

Click the Use this template button at the top of the repository
Select Create a new repository
Select an owner and name for your new repository
Click Create repository
Clone your new repository

Check out your new repository, go to the cloned repo directory, and make sure your node version matches the one in the .node-version file. If you’re using nvm (Node Version Manager), you can run:

cp .node-version .nvmrc
nvm install
node --version

Note: Our example is based on this commit of the template repository.

Implement your custom GitHub Action

Install the template’s dependencies with npm install. In addition, install the @actions/github package with npm install @actions/github.

The template provides a basic structure for your GitHub Action. Update the action.yml file with your action’s name, description, author, and updated inputs/outputs.

name: 'Code review'
description: 'Improved code review process'
author: 'Victor on Software'

# Add your action's branding here. This will appear on the GitHub Marketplace.
branding:
  icon: 'heart'
  color: 'red'

# Define your inputs here.
inputs:
  github-token:
    description: 'GitHub secret token'
    required: true

runs:
  using: node20
  main: dist/index.js

In this example, our new action will have a single input, github-token, the GitHub secret token to use the GitHub API.

Next, we can modify the code in the src/main.ts file to implement our custom logic.

import * as core from '@actions/core'
import * as github from '@actions/github'
import { readFileSync } from 'fs'

/**
 * The main function of the action.
 * @returns {Promise<void>} Resolves when the action is complete.
 */
export async function run(): Promise<void> {
  try {
    // Get the PR number from the payload. This action is only intended for PRs.
    const prNumber = github.context.payload.pull_request?.number
    if (!prNumber) {
      return
    }

    // Get the required reviewer from the REVIEWERS file.
    // This simplified example assumes that the REVIEWERS file contains a single reviewer.
    // In a real-world scenario, we would need to parse the REVIEWERS file at the top directory
    // of our changed files to get the reviewers.
    const reviewer = readFileSync('REVIEWERS', 'utf8').trim()
    if (!reviewer) {
      core.setFailed('No reviewer found in REVIEWERS file')
      return
    }

    // Get all the reviews for this PR.
    const githubToken = core.getInput('github-token')
    const octokit = github.getOctokit(githubToken)
    const reviews = await octokit.rest.pulls.listReviews({
      owner: github.context.repo.owner,
      repo: github.context.repo.repo,
      pull_number: prNumber
    })

    // Check if the required reviewer has approved the PR.
    // This action does not require the reviewer to re-approve the PR if new changes are pushed.
    let approved = false
    reviews.data.forEach(review => {
      if (review.user?.login === reviewer && review.state === 'APPROVED') {
        approved = true
      }
    })

    // Fail the workflow run if the required reviewer has not approved the PR.
    if (!approved) {
      core.setFailed(`Reviewer ${reviewer} needs to approve the PR`)
      return
    }

  } catch (error) {
    // Fail the workflow run if an error occurs
    if (error instanceof Error) core.setFailed(error.message)
  }
}

We read the REVIEWERS file to get the required reviewer for the PR. We then retrieve all the reviews for the pull request and check if the needed reviewer has approved the PR. If the reviewer has not approved the PR, we fail the run.

Build your custom GitHub Action

To build your action, run npm run bundle. This will compile the TypeScript code in the src/ directory and output the JavaScript code in the dist/ directory. The exact command for bundle is defined in the package.json file.

The bundle step is required before you can test your action locally or use it in a workflow because the action.yml file points at the dist/index.js bundled version of your code.

This step can easily be forgotten, and you may wonder why your changes are not reflected in the action. You can configure our IDE to do npm run bundle automatically on save, create a check as a git pre-commit hook to ensure the dist/ directory is up-to-date, or rely on the Check Transpiled Javascript workflow in the .github/workflows/ directory.

Now, commit your changes and push them to your repository.

Note: We will not cover testing in this article, but you should add tests to the __tests__/ directory for your source code. For this example, we must refactor the code to make it more testable.

Test your custom GitHub Action in another repository

Add workflows and REVIEWERS file

You can use the uses keyword in a workflow file to try your action in another repository. Create a new workflow file in the repository’s .github/workflows/ directory where you want to test your action. For example:

name: Code review

on:
  workflow_dispatch: # Manual (for debug)
  pull_request:

jobs:
  code-review:
    name: Code review
    runs-on: ubuntu-latest
    steps:
      - name: Checkout
        id: checkout
        uses: actions/checkout@v4
      - name: Code review action
        id: test-action
        uses: getvictor/code-review-demo@main # Your action goes here
        with:
          github-token: ${{ secrets.GITHUB_TOKEN }}

We are using @main as the version of the action to test the latest code on the main branch. You can replace this with a specific version tag or branch name.

In addition, create a REVIEWERS file at the repository’s root with the required reviewer’s GitHub username.

Notice that the above workflow runs on pull_request events but not on pull_request_review events. This is because GitHub Actions treats the pull_request workflow runs and the pull_request_review workflow runs as distinct. Instead, we want the same workflow run to be triggered by both events. This is a common pitfall when working with GitHub Actions. We need to add another workflow file that listens for pull_request_review events and triggers the pull_request workflow run to fix this.

name: Rerun checks after review

on:
  pull_request_review:
    types:
      - submitted
      - dismissed

jobs:
  rerun_checks:
    name: Rerun specified checks
    permissions:
      actions: write
    runs-on: ubuntu-latest
    steps:
      - name: Rerun Checks
        uses: shqear93/rerun-checks@v3
        with:
          github-token: ${{ secrets.GITHUB_TOKEN }}
          check-names: 'Code review'

Configure a GitHub rule to require code review

Create a branch protection rule in the repository settings that requires the above Code review workflow to pass in a PR before merging to your default branch.

Require a pull request before merging. Require the Code review status check to pass.

Create a pull request

Commit your changes to a new branch and create a pull request. The Code review workflow should run automatically and show the Failed status.

Once the required reviewer approves the PR, the Rerun checks after review workflow will run and trigger the Code review workflow. The rerun should pass, and you should be able to merge the PR.

Clean up your custom GitHub Action repo

As an optional step, you can clean up your custom GitHub Action repository:

Update README.md with instructions on how to use your new action
Remove the src/wait.ts file and associated tests
Update workflows in the .github/workflows/ directory

Example code on GitHub

The code for our simple GitHub Action is available on GitHub: https://github.com/getvictor/code-review-demo
