This article will present a problem we encountered in our production distributed system and how we solved it using a distributed lock.
The problem – data inconsistency
Recently, we started using the Google Calendar API to monitor calendar changes. However, we noticed that it is possible to receive a second callback while processing the first one. This second callback can lead to data inconsistency, race conditions, and deadlocks.
Data inconsistency
In the above diagram, two servers, A and B, are processing calendar events. Server B receives a callback from Google Calendar API stating that something has changed in the calendar. Google does not provide information about what event changed, so server B must fetch the event of interest from the calendar. While server B is fetching the event, server A also receives a callback. Server A also fetches the event from the calendar. Both servers now have the same event but are unaware of each other’s actions. Server B updates the event with new information. Server A also updates the event with different details, potentially overwriting or duplicating Server B’s changes. The calendar event is now in an inconsistent state, as is the data in our database.
What is a distributed lock?
A distributed lock is a mechanism that allows multiple servers to coordinate access to a shared resource. This mechanism is widely used across the software industry to ensure data consistency in distributed systems.
In our case, we need to make sure that only one server is processing a calendar event at a time. The distributed lock will prevent the second server from processing the event until the first server completes.
Implementation of distributed lock
We implemented a distributed lock using Redis. Redis is an in-memory data structure store that can be used as a database, cache, and message broker. To acquire the lock, our server sets a key in Redis with a unique value using the Redis SET command.
SET mykey "myvalue" NX PX 60000
The NX
option only sets the key if it does not exist. The PX 60000
option sets the key’s expiration time to 60
seconds. This ensures that the lock is released if the server crashes or does not release it in a timely manner.
To release the lock, we EVAL
a Lua script that checks if the key’s value matches the unique value set by the server.
If the values match, the script deletes the key using the
Redis DEL command.
if redis.call("get", KEYS[1]) == ARGV[1] then
return redis.call("del", KEYS[1])
else
return 0
end
We only release the lock if the value matches, ensuring that the server that acquired the lock releases it.
Distributed lock solution
With the distributed lock in place, we can make sure that only one server is processing a calendar event at a time.
Using distributed lock with a processing queue
In the above diagram, server B receives a calendar callback and acquires a lock from Redis. Server A also gets a callback but cannot acquire the lock since it has already been taken by Server B. Instead of waiting, Server A puts the event in a processing queue. Once Server B finishes processing the event, it releases the lock. Server B then checks the queue. Finding an event in the queue, the server starts a new worker process to process the events. The worker processes all outstanding events in the queue and exits on completion.
Waiting to acquire the lock
One issue we encountered was that another system process needed to acquire the lock. The process could keep trying to obtain the lock, but there was no guarantee that it would be successful in a reasonable amount of time because it could compete with other servers.
Fairness in acquiring the lock
We implemented a fairness mechanism to ensure a priority process could acquire the lock.
Cron job is guaranteed to acquire the lock
In the above diagram, the worker process has acquired the lock. Another process, a cron job, also needs to acquire the lock. The cron job is a priority process that needs to run at a specific time. The cron job tries to acquire the lock but fails because the worker process has it. The cron job sets a key in Redis that indicates that it wants to acquire the lock next. This action tells the other servers not to acquire the lock. The cron job then retries acquiring the lock until it is successful.
Distributed lock code on GitHub
We implemented the distributed lock logic in Go. The crucial part of the code is in the redis_lock.go file.
Distributed lock video
Note: If you want to comment on this article, please do so on the YouTube video.
